2HP 230V AF-300 E11 GE Fuji AFD AC Drive AF-300-E11 VFD

$0.00 - Email me the quote or
Submit online question to us
SKU:
AF-300-E11
Condition:
New
Availability:
Call 1-847-886-2616 or email to support@redrive.net for available purchasing, exchange or repair options and pricing
Quantity:

Product Description

2HP 230V AF-300 E11 GE Fuji Adjustable Frequency AC Drive / Inverter AF-300-E11

Condition: New.

Adjustable frequency vector control AC drive.

The AF-300 E11 adjustable frequency drive is GE Fuji Drives' new generation of micro drives. GE Fuji Drives recognized your need for a high performance, full featured compact drive and designed the AF-300 E11 drive with these features in mind. This product is specifically intended for original equipment manufacturers who require maximum performance in a minimal space for a cost effective system.

Features

  • Dynamic torque vector control
    Provides optimal control of voltage and current vectors for maximum output torque

  • High starting torque
    Capable of moving heavy loads like a conveyor, lift, and/or traverse

  • Compact design
    Fit easily into limited space applications

  • Uniform height dimension
    Standardizes panel design

  • Low noise
    Minimizes influence to devices such as sensors

  • Automatic energy-saving function
    Reduces motor loss and electric costs

  • Online tuning
    Detects the secondary resistance of the motor and maintains stable rotation regardless of variation in motor temperature

  • Catch a spinning motor
    Restarts a rotating motor without shock

  • PID control function
    Eliminates need for some external process controls

  • Soft-switching IGBTs
    Allows use with standard general purpose motors

  • Built-in RS485
    Allow low cost system integration using the RTU protocol

  • Configuration software
    Configures different drive with Windows-based software

  • Inrush current control circuit
    Allows use of peripheral equipment having smaller capacity

  • Compliance with major international standards
    Assurance of smooth integration with global equipment requiring CE, TUV, UL, CUL

AF-300 E11 Operation and Maintenance Manual

Specification:

Part Number6KE1123002X1A1
Mfg NameGE FUJI Electric
Rated InputAC3PH 200-230VAC (3-Phase) 50/60Hz 11.1A
Rated OutputAC3PH 2HP 7.0Amp 0.2-400Hz
Temperature Range-10C to +50C (14F to 122F)
Protection levelIP20 /NEMA1
Overload capability150% for 60 seconds
Control methodV/f, Sinusoidal PWM (Dynamic torque vector control) with "current vibration suppression function" and "dead time compensation function"
Setpoint resolutionAnalog reference: 1/3000 of maximum output frequency Keypad panel reference: 0.01 Hz (99.99 Hz or lower), 0.1 Hz (100.0 to 400.0 Hz) LAN reference : 1/20000 of Maximum frequency (0.003Hz at 60Hz,0.006Hz at 120Hz,0.02Hz at 400Hz), or 0.01Hz (Fixed)
Serial interfaceRS485
StandardsUL, cUL, CE
Shipping weight7 lb
